ATE Original 2 Pieces Brake Drum (24022000461) for Citroën, Peugeot, Toyota
€116.16
(tax incl.)
€96.00 tax excl.
Part-number:
ATE 24.0220-0046.1
(240220-00461)
- Outer diameter [mm]: 233,0
- Inner diameter [mm]: 200,0
- Support plate diameter [mm]: 55,0
- Number of Bolt Holes: 4
- 2 Pieces of Brake Drum
- Trade Number: 480193
- Ean Code: 4006633295857
- Weight: 7.44kg
Specification of ATE 24.0220-0046.1 / 240220-00461 / 24022000461:
| OE Number | Reference info |
| CITROËN 4247 48 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CITROËN 424748 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 4247 48 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 424748 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| TOYOTA 42431-0H010 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| CITROËN C1 (PM_, PN_) Construction Year to 201404 Fitting Position Rear Axle | 2005-06 - 2014-09 | 50 | 68 | 998 | Hatchback |
| CITROËN C1 (PM_, PN_) Construction Year to 200812 Fitting Position Rear Axle | 2005-06 - 2014-09 | 40 | 54 | 1398 | Hatchback |
| CITROËN C1 II (PA_, PS_) Fitting Position Rear Axle | 2014-04 - 2018-04 | 51 | 69 | 998 | Hatchback |
| CITROËN C1 II (PA_, PS_) Fitting Position Rear Axle | 2018-06 - 2021-07 | 53 | 72 | 998 | Hatchback |
| CITROËN C1 II (PA_, PS_) Fitting Position Rear Axle | 2014-04 - 2018-04 | 60 | 82 | 1199 | Hatchback |
| PEUGEOT 107 (PM_, PN_) Fitting Position Rear Axle | 2005-06 - 2014-05 | 50 | 68 | 998 | Hatchback |
| PEUGEOT 107 (PM_, PN_) Fitting Position Rear Axle | 2005-06 - 2014-05 | 40 | 54 | 1398 | Hatchback |
| PEUGEOT 108 Fitting Position Rear Axle | 2014-05 - | 51 | 69 | 998 | Hatchback |
| PEUGEOT 108 Fitting Position Rear Axle | 2018-05 - | 53 | 72 | 998 | Hatchback |
| PEUGEOT 108 Fitting Position Rear Axle | 2014-05 - | 60 | 82 | 1199 | Hatchback |
| TOYOTA AYGO (_B1_) Fitting Position Rear Axle | 2005-07 - 2014-05 | 50 | 68 | 998 | Hatchback |
| TOYOTA AYGO (_B1_) Fitting Position Rear Axle | 2005-07 - 2014-05 | 50 | 68 | 998 | Hatchback |
| TOYOTA AYGO (_B1_) Fitting Position Rear Axle | 2005-07 - 2010-08 | 40 | 54 | 1398 | Hatchback |
| TOYOTA AYGO (_B4_) Fitting Position Rear Axle | 2014-05 - | 51 | 69 | 998 | Hatchback |
| TOYOTA AYGO (_B4_) Fitting Position Rear Axle | 2018-03 - | 53 | 72 | 998 | Hatchback |
| TOYOTA AYGO (_B4_) Fitting Position Rear Axle | 2014-05 - | 60 | 82 | 1199 | Hatchback |
| TOYOTA AYGO Hatchback Van (_B1_) Fitting Position Rear Axle | 2005-07 - 2014-05 | 50 | 68 | 998 | Hatchback Van |
24.0220-0046.1
Data sheet
- Article Status
- Orderable
- Car Brand
- Citroën
Peugeot
Toyota - Trade Number
- 480193
- Country Of Origin
- China
- Height
- 53,7
- Outer Diameter [mm]
- 233,0
- Number of Bolt Holes
- 4
- Bolt Hole Diameter [mm]
- 100,0
- Support Plate Diameter [mm]
- 55,0
- Inner Diameter [mm]
- 200,0
- Bore Diameter [mm]
- 13,2
- Max. Reboring Dimension [mm]
- 201,0
- Brake Drum Inner Height [mm]
- 44,0
Specific References
- EAN13
- 4006633295857
- MPN
- 2402200046102
ATE 24.0220-0046.1
(240220-00461)
- Outer diameter [mm]: 233,0
- Inner diameter [mm]: 200,0
- Support plate diameter [mm]: 55,0
- Number of Bolt Holes: 4
- 2 Pieces of Brake Drum
- Trade Number: 480193
