ATE Original 2 Pieces Brake Drum (24022000451) for Opel, Suzuki
€83.49
(tax incl.)
€69.00 tax excl.
Part-number:
ATE 24.0220-0045.1
(240220-00451)
- Outer diameter [mm]: 232,0
- Inner diameter [mm]: 200,0
- Support plate diameter [mm]: 52,0
- Number of Bolt Holes: 4
- 2 Pieces of Brake Drum
- Trade Number: 480189
- Ean Code: 4006633285605
- Weight: 10.24kg
Specification of ATE 24.0220-0045.1 / 240220-00451 / 24022000451:
| OE Number | Reference info |
| OPEL 47 07 272 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| OPEL 4707272 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| OPEL 9214294 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| SUZUKI 43511-85E50 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 47 07 272 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 4707272 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 9214294 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| OPEL AGILA A (H00) Vehicle Identification Number (VIN) from 4G000001 Construction Year to 200707 Fitting Position Rear Axle | 2000-09 - 2007-12 | 43 | 58 | 973 | Hatchback |
| OPEL AGILA A (H00) Vehicle Identification Number (VIN) from 4G000001 Construction Year to 200707 Fitting Position Rear Axle | 2003-08 - 2007-12 | 44 | 60 | 998 | Hatchback |
| OPEL AGILA A (H00) Vehicle Identification Number (VIN) from 4G000001 Construction Year to 200707 Fitting Position Rear Axle | 2000-09 - 2007-12 | 55 | 75 | 1199 | Hatchback |
| OPEL AGILA A (H00) Vehicle Identification Number (VIN) from 4G000001 Construction Year to 200707 Fitting Position Rear Axle | 2004-07 - 2007-12 | 59 | 80 | 1229 | Hatchback |
| OPEL AGILA A (H00) Vehicle Identification Number (VIN) from 4G000001 Construction Year to 200707 Fitting Position Rear Axle | 2003-08 - 2007-12 | 51 | 70 | 1248 | Hatchback |
| SUZUKI WAGON R+ (MA) Fitting Position Rear Axle | 2003-09 - 2006-08 | 69 | 94 | 1328 | Hatchback |
| SUZUKI WAGON R+ (MA) Construction Year to 200804 Fitting Position Rear Axle | 2003-09 - | 51 | 70 | 1248 | Hatchback |
| SUZUKI WAGON R+ (MA) Fitting Position Rear Axle | 2005-01 - 2008-12 | 59 | 80 | 1229 | Hatchback |
24.0220-0045.1
Data sheet
- Article Status
- Orderable
- Car Brand
- Opel
Suzuki - Trade Number
- 480189
- Country Of Origin
- China
- Additional Info
- without ABS sensor ring
without wheel bearing - Height
- 75,5
- Outer Diameter [mm]
- 232,0
- Number of Bolt Holes
- 4
- Bolt Hole Diameter [mm]
- 100,0
- Support Plate Diameter [mm]
- 52,0
- Inner Diameter [mm]
- 200,0
- Thread Size
- M12x1,5
- Max. Reboring Dimension [mm]
- 202,0
- Brake Drum Inner Height [mm]
- 38,0
- Brake Drum Inner Diameter [mm]
- 47,0
Specific References
- EAN13
- 4006633285605
- MPN
- 2402200045102
ATE 24.0220-0045.1
(240220-00451)
- Outer diameter [mm]: 232,0
- Inner diameter [mm]: 200,0
- Support plate diameter [mm]: 52,0
- Number of Bolt Holes: 4
- 2 Pieces of Brake Drum
- Trade Number: 480189
