ATE Original-2-teilige Bremstrommel (24022000381) für Opel
98,01 €
(inkl. MwSt.)
81,00 € Steuerexzl.
Teilenummer:
ATE 24.0220-0038.1
(240220-00381)
- Außendurchmesser [mm]: 228,0
- Innendurchmesser [mm]: 200,0
- Trägerplattendurchmesser [mm]: 53,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480162
- Ean-Code: 4006633106962
- Gewicht: 11.50kg
Specification of ATE 24.0220-0038.1 / 240220-00381 / 24022000381:
| OE Number | Reference info |
| OPEL 4 18 001 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| OPEL 418001 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| OPEL 9196290 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 4 18 001 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 418001 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAUXHALL 9196290 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-09 - 2003-06 | 43 | 58 | 973 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2003-06 - 2009-12 | 44 | 60 | 998 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2000-09 - 2009-12 | 55 | 75 | 1199 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2004-07 - 2009-12 | 59 | 80 | 1229 | Hatchback |
| OPEL CORSA C (X01) Construction Year to 200609 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2003-06 - 2009-12 | 66 | 90 | 1364 | Hatchback |
| OPEL CORSA C (X01) Construction Year to 200609 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-09 - 2009-12 | 66 | 90 | 1389 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2003-06 - 2009-12 | 51 | 70 | 1248 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2000-09 - 2009-12 | 48 | 65 | 1686 | Hatchback |
| OPEL CORSA C (X01) Braking/Driving Dynamics for vehicles with ABS Construction Year to 200609 Fitting Position Rear Axle | 2000-09 - 2009-12 | 55 | 75 | 1686 | Hatchback |
| OPEL TIGRA TwinTop (X04) Construction Year to 200908 Fitting Position Rear Axle | 2004-06 - 2010-12 | 66 | 90 | 1364 | Convertible |
| OPEL TIGRA TwinTop (X04) Construction Year to 200908 Fitting Position Rear Axle | 2004-06 - 2010-12 | 92 | 125 | 1796 | Convertible |
| OPEL TIGRA TwinTop (X04) Construction Year to 200908 Fitting Position Rear Axle | 2004-06 - 2010-12 | 51 | 69 | 1248 | Convertible |
| OPEL CORSA C Hatchback Van (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-09 - 2003-07 | 55 | 75 | 1199 | Hatchback Van |
| OPEL CORSA C Hatchback Van (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2005-07 - 2006-06 | 59 | 80 | 1229 | Hatchback Van |
| OPEL CORSA C Hatchback Van (X01) Construction Year to 200609 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2003-08 - 2012-06 | 66 | 90 | 1364 | Hatchback Van |
| OPEL CORSA C Hatchback Van (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2005-07 - 2006-06 | 51 | 69 | 1248 | Hatchback Van |
| OPEL CORSA C Hatchback Van (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-09 - 2003-07 | 48 | 65 | 1686 | Hatchback Van |
| OPEL CORSA C Hatchback Van (X01) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-09 - 2003-07 | 55 | 75 | 1686 | Hatchback Van |
24.0220-0038.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Opel
- Handelsnummer
- 480162
- Herkunftsland
- Italien
- Zusätzliche Informationen
- ohne ABS-Sensorring
ohne Radlager - Höhe
- 94,2
- Außendurchmesser [mm]
- 228,0
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 100,0
- Trägerplattendurchmesser [mm]
- 53,0
- Innendurchmesser [mm]
- 200,0
- Gewindegröße
- M12x1,5
- Max. Bohrende Dimension [mm]
- 201,0
- Innenhöhe der Bremstrommel [mm]
- 54,0
- Innendurchmesser der Bremstrommel [mm]
- 47,2
Spezifische Referenzen
- ean13
- 4006633106962
- Hersteller-Teilenummer (MPN)
- 2402200038102
ATE 24.0220-0038.1
(240220-00381)
- Außendurchmesser [mm]: 228,0
- Innendurchmesser [mm]: 200,0
- Trägerplattendurchmesser [mm]: 53,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480162
