ATE Original zweiteilige Bremstrommel (24022030131) für Citroën, Peugeot
159,72 €
(inkl. MwSt.)
132,00 € Steuerexzl.
Teilenummer:
ATE 24.0220-3013.1
(240220-30131)
- Außendurchmesser [mm]: 247,0
- Innendurchmesser [mm]: 203,0
- Trägerplattendurchmesser [mm]: 52,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480089
- Ean-Code: 4006633007627
- Gewicht: 13.57kg
Specification of ATE 24.0220-3013.1 / 240220-30131 / 24022030131:
| OE Number | Reference info |
| CITROËN 4247 45 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CITROËN 424745 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CITROËN 4247 41 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CITROËN 424741 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 4247 45 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 424745 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 4247 41 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 424741 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 4247 47 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PEUGEOT 424747 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-11 - 2003-06 | 20 | 27 | CC | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 1998-11 | 33 | 45 | 954 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-05 - 2003-06 | 37 | 50 | 954 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2003-09 | 40 | 54 | 1124 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2003-09 | 44 | 60 | 1124 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2000-07 - 2003-06 | 44 | 60 | 1124 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2003-06 | 55 | 75 | 1360 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2003-06 | 65 | 88 | 1587 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-02 - 2003-06 | 66 | 90 | 1587 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-09 - 2003-09 | 40 | 54 | 1527 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-09 - 2001-06 | 42 | 57 | 1527 | Hatchback |
| CITROËN SAXO (S0, S1) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2001-07 - 2004-04 | 43 | 58 | 1527 | Hatchback |
| CITROËN SAXO Hatchback van (S3_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1999-08 - 2001-06 | 42 | 57 | 1527 | Hatchback Van |
| CITROËN SAXO Hatchback van (S3_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2001-07 - 2003-06 | 43 | 58 | 1527 | Hatchback Van |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 1999-10 | 33 | 45 | 954 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-04 - 2001-03 | 37 | 50 | 954 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1997-01 - 2001-03 | 40 | 54 | 1124 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Construction Year to 200403 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2004-07 | 44 | 60 | 1124 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-04 - 2001-03 | 44 | 60 | 1124 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Construction Year to 200403 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2004-07 | 55 | 75 | 1360 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 1999-10 | 65 | 89 | 1587 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1996-05 - 2001-03 | 40 | 55 | 1527 | Hatchback |
| PEUGEOT 106 II (1A_, 1C_) Construction Year from 200010 Construction Year to 200403 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-04 - 2004-07 | 42 | 57 | 1527 | Hatchback |
| PEUGEOT 206+ (2L_, 2M_) Construction Year to 201305 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2009-01 - 2013-06 | 44 | 60 | 1124 | Hatchback |
| PEUGEOT 206+ (2L_, 2M_) Construction Year to 201305 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2009-04 - 2013-06 | 44 | 60 | 1124 | Hatchback |
| PEUGEOT 206+ (2L_, 2M_) Construction Year to 201305 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2010-09 - 2013-06 | 54 | 73 | 1360 | Hatchback |
| PEUGEOT 206+ (2L_, 2M_) Construction Year to 201305 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2009-01 - 2013-08 | 55 | 75 | 1360 | Hatchback |
| PEUGEOT 206+ (2L_, 2M_) Construction Year to 201305 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2009-01 - 2013-06 | 50 | 68 | 1398 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Construction Year from 199809 for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-08 - 2000-07 | 40 | 54 | 1124 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-09 - 2007-02 | 44 | 60 | 1124 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-09 - 2012-12 | 55 | 75 | 1360 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Fitting Position Rear Axle | 2003-10 - 2008-02 | 65 | 88 | 1360 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-09 - 2000-12 | 65 | 89 | 1587 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Fitting Position Rear Axle | 2001-06 - 2009-04 | 79 | 107 | 1587 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Construction Year to 200902 Fitting Position Rear Axle | 2000-07 - 2009-04 | 80 | 109 | 1587 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Construction Year to 200902 Fitting Position Rear Axle | 2000-07 - 2009-04 | 80 | 109 | 1587 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2001-09 - 2009-04 | 50 | 68 | 1398 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1998-09 - 2001-11 | 51 | 69 | 1868 | Hatchback |
| PEUGEOT 206 Hatchback (2A/C) Construction Year to 200902 Fitting Position Rear Axle | 1999-12 - 2009-09 | 66 | 90 | 1997 | Hatchback |
| PEUGEOT 206 SW (2E/K) for RPO number up to 10254 Fitting Position Rear Axle | 2002-07 - 2007-02 | 44 | 60 | 1124 | Estate |
| PEUGEOT 206 SW (2E/K) for RPO number up to 10254 Fitting Position Rear Axle | 2002-07 - 2007-02 | 55 | 75 | 1360 | Estate |
| PEUGEOT 206 SW (2E/K) for RPO number up to 10254 Fitting Position Rear Axle | 2002-07 - 2007-02 | 50 | 68 | 1398 | Estate |
| PEUGEOT 206 SW (2E/K) for RPO number up to 10254 Fitting Position Rear Axle | 2002-07 - 2007-02 | 66 | 90 | 1997 | Estate |
| PEUGEOT 206 Saloon Construction Year to 200902 Fitting Position Rear Axle | 2007-03 - | 80 | 109 | 1587 | Saloon |
| PEUGEOT 206 Van for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2002-09 - 2007-02 | 44 | 60 | 1124 | Hatchback Van |
| PEUGEOT 206 Van for RPO number up to 10254 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 2001-09 - 2009-03 | 50 | 68 | 1398 | Hatchback Van |
24.0220-3013.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Citroën
Peugeot - Handelsnummer
- 480089
- Herkunftsland
- China
- Zusätzliche Informationen
- ohne ABS-Sensorring
ohne Radlager - Höhe
- 71,5
- Außendurchmesser [mm]
- 247,0
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 108,0
- Trägerplattendurchmesser [mm]
- 52,0
- Innendurchmesser [mm]
- 203,0
- Gewindegröße
- M12x1,25
- Max. Bohrende Dimension [mm]
- 204,5
- Innenhöhe der Bremstrommel [mm]
- 46,5
Spezifische Referenzen
- ean13
- 4006633007627
- Hersteller-Teilenummer (MPN)
- 2402203013102
ATE 24.0220-3013.1
(240220-30131)
- Außendurchmesser [mm]: 247,0
- Innendurchmesser [mm]: 203,0
- Trägerplattendurchmesser [mm]: 52,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480089
