ATE Originaler zweiteiliger Bremstrommel (24022500011) für BMW
79,86 €
(inkl. MwSt.)
66,00 € Steuerexzl.
Teilenummer:
ATE 24.0225-0001.1
(240225-00011)
- Außendurchmesser [mm]: 285,0
- Innendurchmesser [mm]: 250,0
- Trägerplattendurchmesser [mm]: 58,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480043
- Ean-Code: 4006633057899
- Gewicht: 9.99kg
Specification of ATE 24.0225-0001.1 / 240225-00011 / 24022500011:
| OE Number | Reference info |
| BMW 34 21 1 158 712 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| BMW 34211158712 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| BMW 34 21 1 117 047 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| BMW 34211117047 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| BMW 3 (E21) Construction Year from 198104 Construction Year to 198312 Fitting Position Rear Axle | 1981-03 - 1984-03 | 55 | 75 | 1573 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1975-08 - 1980-08 | 66 | 90 | 1573 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1980-09 - 1982-12 | 66 | 90 | 1766 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1975-08 - 1980-08 | 72 | 98 | 1766 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1979-11 - 1982-08 | 77 | 105 | 1766 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1975-06 - 1979-07 | 80 | 109 | 1990 | Saloon |
| BMW 3 (E21) Fitting Position Rear Axle | 1977-08 - 1982-10 | 90 | 122 | 1990 | Saloon |
| BMW 3 (E21) Construction Year from 197809 Fitting Position Rear Axle Country Specific Design USA | 1975-06 - 1982-08 | 92 | 125 | 1990 | Saloon |
| BMW 3 (E21) Construction Year from 197510 Construction Year to 197807 Fitting Position Rear Axle | 1975-06 - 1982-08 | 92 | 125 | 1990 | Saloon |
| BMW 3 (E30) Construction Year to 198312 Fitting Position Rear Axle | 1982-09 - 1991-12 | 55 | 75 | 1573 | Saloon |
| BMW 1500-2000 (115, 116, 118, 121) Fitting Position Rear Axle | 1969-07 - 1971-09 | 66 | 90 | 1766 | Saloon |
| BMW 1500-2000 (115, 116, 118, 121) Construction Year from 196901 Fitting Position Rear Axle | 1963-08 - 1969-09 | 66 | 90 | 1773 | Saloon |
| BMW 1500-2000 (115, 116, 118, 121) Construction Year to 197112 Fitting Position Rear Axle | 1970-01 - 1972-11 | 66 | 90 | 1766 | Saloon |
24.0225-0001.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- BMW
- Handelsnummer
- 480043
- Herkunftsland
- China
- Höhe
- 62,5
- Außendurchmesser [mm]
- 285,0
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 100,0
- Trägerplattendurchmesser [mm]
- 58,0
- Innendurchmesser [mm]
- 250,0
- Bohrdurchmesser [mm]
- 14,5
- Max. Bohrende Dimension [mm]
- 251,0
- Innenhöhe der Bremstrommel [mm]
- 47,0
Spezifische Referenzen
- ean13
- 4006633057899
- Hersteller-Teilenummer (MPN)
- 2402250001102
ATE 24.0225-0001.1
(240225-00011)
- Außendurchmesser [mm]: 285,0
- Innendurchmesser [mm]: 250,0
- Trägerplattendurchmesser [mm]: 58,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480043
