ATE Originale zweiteilige Bremsscheibe (24011201601) für Renault
108,90 €
(inkl. MwSt.)
90,00 € Steuerexzl.
Teilenummer:
ATE 24.0112-0160.1
(240112-01601)
- Außendurchmesser [mm]: 280,5
- Innendurchmesser [mm]: 149,0
- Bremsscheibendicke [mm]: 12,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile Bremsscheiben
- Handelsnummer: 412160
Logistische Informationen:
- Ean-Code: 4006633263962
- Gewicht: 10.50kg
Specification of ATE 24.0112-0160.1 / 240112-01601 / 24011201601:
| OE Number | Reference info |
| RENAULT 77 01 207 227 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| RENAULT 7701207227 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| RENAULT 86 71 019 318 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| RENAULT 8671019318 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| RENAULT KANGOO (KC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2001-10 - | 70 | 95 | 1598 | MPV |
| RENAULT KANGOO (KC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2001-10 - | 59 | 80 | 1870 | MPV |
| RENAULT KANGOO (KC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2003-10 - | 62 | 84 | 1870 | MPV |
| RENAULT KANGOO Rapid (FC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2001-10 - | 70 | 95 | 1598 | Box Body/MPV |
| RENAULT KANGOO Rapid (FC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2001-10 - | 59 | 80 | 1870 | Box Body/MPV |
| RENAULT KANGOO Rapid (FC0/1_) Construction Year to 200712 Fitting Position Rear Axle | 2003-07 - | 62 | 84 | 1870 | Box Body/MPV |
24.0112-0160.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Renault
- Handelsnummer
- 412160
- Herkunftsland
- Italien
- Höhe
- 45,1
- Außendurchmesser [mm]
- 280,5
- Bremsscheibendicke [mm]
- 12,0
- Bremsscheibentyp
- Solide
- Oberfläche
- Coated
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 100,0
- Zentrierungsdurchmesser [mm]
- 61,0
- Innendurchmesser [mm]
- 149,0
- Bohrdurchmesser [mm]
- 13,5
- Mindestdicke [mm]
- 11,0
Spezifische Referenzen
- ean13
- 4006633263962
- Hersteller-Teilenummer (MPN)
- 2401120160102
ATE 24.0112-0160.1
(240112-01601)
- Außendurchmesser [mm]: 280,5
- Innendurchmesser [mm]: 149,0
- Bremsscheibendicke [mm]: 12,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile Bremsscheiben
- Handelsnummer: 412160
