ATE Original Brake Disk (24011602161) for Ford

€163.35 (tax incl.)

€135.00 tax excl.

Part-number:

ATE 24.0116-0216.1
(240116-02161)

  • Outer Diameter [mm]: 280,0
  • Inner Diameter [mm]: 120,0
  • Brake Disc Thickness [mm]: 16,0
  • Number of Bolt Holes: 5
  • Trade Number: 416216
Logistical information:
96,0Click here for detailed information.
  • Ean Code: 4006633446037
  • Weight: 8.75kg
Quantity

Specification of ATE 24.0116-0216.1 / 240116-02161 / 24011602161:

OE NumberReference info
FORD 1387152Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
FORD 1451161Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)

ModelModel YearkWHPCCType
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2006-04 - 2014-0863852198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2011-10 - 2014-08741002198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2006-04 - 2014-08811102198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2008-10 - 2014-08851152198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2011-10 - 2014-08921252198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2006-04 - 2014-08961302198Van
FORD TRANSIT Van (FA_ _)

Fitting Position Rear Axle		2007-10 - 2014-081031402198Van
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2006-04 - 2014-0863852198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2011-10 - 2014-08741002198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2006-04 - 2014-08811102198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2008-10 - 2014-08851152198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2011-10 - 2014-08921252198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2006-04 - 2014-08961302198Platform/Chassis
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Fitting Position Rear Axle		2007-10 - 2014-081031402198Platform/Chassis
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Construction Year from 200605

Fitting Position Rear Axle		2006-04 - 2014-0863852198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2011-10 - 2014-08741002198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2006-04 - 2014-08811102198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2008-10 - 2014-08851152198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2011-10 - 2014-08921252198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2006-04 - 2014-08961302198Bus
FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Fitting Position Rear Axle		2007-10 - 2014-081031402198Bus
FORD TRANSIT TOURNEO Bus

Fitting Position Rear Axle		2006-07 - 2014-08811102198Bus
FORD TRANSIT TOURNEO Bus

Fitting Position Rear Axle		2008-10 - 2014-08851152198Bus
FORD TRANSIT TOURNEO Bus

Fitting Position Rear Axle		2011-10 - 2014-08921252198Bus
FORD TRANSIT TOURNEO Bus

Fitting Position Rear Axle		2006-07 - 2014-08961312198Bus
FORD TRANSIT TOURNEO Bus

Fitting Position Rear Axle		2007-10 - 2014-081031402198Bus
24.0116-0216.1

Data sheet

Article Status
Orderable
Car Brand
Ford
Trade Number
416216
Country Of Origin
Italy
Additional Info
with ABS sensor ring
Height
68,7
Outer Diameter [mm]
280,0
Brake Disc Thickness [mm]
16,0
Brake Disc Type
solid
Surface
Coated
Number of Bolt Holes
5
Bolt Hole Diameter [mm]
160,0
Centering Diameter [mm]
96,0
Inner Diameter [mm]
120,0
Thread Size
M10x1,5
Minimum Thickness [mm]
13,0

Specific References

EAN13
4006633446037
MPN
2401160216102
