2 pieces of ATE original Brake Disk (24012701041) for Isuzu
€137.94
(tax incl.)
€114.00 tax excl.
Part-number:
ATE 24.0127-0104.1
(240127-01041)
- Outer Diameter [mm]: 280,0
- Inner Diameter [mm]: 148,0
- Brake Disc Thickness [mm]: 27,0
- Number of Bolt Holes: 6
- 2 pieces of Brake Disc
- Trade Number: 427104
Logistical information:
- Ean Code: 4006633470056
- Weight: 14.10kg
Specification of ATE 24.0127-0104.1 / 240127-01041 / 24012701041:
| OE Number | Reference info |
| ISUZU 8-98006-259-0 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| ISUZU 8-97360-678-0 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| ISUZU 8-98006-259-1 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| ISUZU D-MAX I (TFR, TFS) Fitting Position Front Axle Construction Year from 200601 | 2002-10 - 2012-06 | 74 | 101 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2006-10 - 2012-06 | 100 | 136 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 100 | 136 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Pickup |
| ISUZU D-MAX II (TFR, TFS) Construction Year from 201510 Fitting Position Front Axle Vehicle Equipment for vehicles with Single Cab | 2012-04 - 2018-12 | 120 | 163 | 2499 | Pickup |
| ISUZU D-MAX I Platform/Chassis (TFR, TFS) Fitting Position Front Axle | 2006-10 - 2012-10 | 100 | 136 | 2499 | Platform/Chassis |
| ISUZU D-MAX I Platform/Chassis (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Platform/Chassis |
| ISUZU D-MAX II Platform/Chassis (TFR, TFS) Construction Year from 201510 Fitting Position Front Axle Vehicle Equipment for vehicles with Single Cab | 2012-06 - | 120 | 163 | 2499 | Platform/Chassis |
24.0127-0104.1
Data sheet
- Article Status
- Orderable
- Car Brand
- Isuzu
- Trade Number
- 427104
- Country Of Origin
- Italy
- Height
- 40,0
- Outer Diameter [mm]
- 280,0
- Brake Disc Thickness [mm]
- 27,0
- Brake Disc Type
- Vented
- Surface
- Coated
- Number of Bolt Holes
- 6
- Bolt Hole Diameter [mm]
- 109,0
- Centering Diameter [mm]
- 88,0
- Inner Diameter [mm]
- 148,0
- Thread Size
- M12x1,25
- Minimum Thickness [mm]
- 25,6
Specific References
- EAN13
- 4006633470056
- MPN
- 2401270104102
ATE 24.0127-0104.1
(240127-01041)
- Outer Diameter [mm]: 280,0
- Inner Diameter [mm]: 148,0
- Brake Disc Thickness [mm]: 27,0
- Number of Bolt Holes: 6
- 2 pieces of Brake Disc
- Trade Number: 427104
