ATE Disco de freno original de 2 piezas (24012701041) para Isuzu
137,94 €
(impuestos inc.)
114,00 € fiscales excl.
Número de parte:
ATE 24.0127-0104.1
(240127-01041)
- Diámetro exterior [mm]: 280,0
- Diámetro interior [mm]: 148,0
- Grosor del disco de freno [mm]: 27,0
- Número de agujeros de perno: 6
- 2 piezas de disco de freno
- Número de intercambio: 427104
Información logística:
- Código Ean: 4006633470056
- Peso: 14.10kg
Specification of ATE 24.0127-0104.1 / 240127-01041 / 24012701041:
| OE Number | Reference info |
| ISUZU 8-98006-259-0 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| ISUZU 8-97360-678-0 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| ISUZU 8-98006-259-1 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| ISUZU D-MAX I (TFR, TFS) Fitting Position Front Axle Construction Year from 200601 | 2002-10 - 2012-06 | 74 | 101 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2006-10 - 2012-06 | 100 | 136 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 100 | 136 | 2499 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Pickup |
| ISUZU D-MAX I (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Pickup |
| ISUZU D-MAX II (TFR, TFS) Construction Year from 201510 Fitting Position Front Axle Vehicle Equipment for vehicles with Single Cab | 2012-04 - 2018-12 | 120 | 163 | 2499 | Pickup |
| ISUZU D-MAX I Platform/Chassis (TFR, TFS) Fitting Position Front Axle | 2006-10 - 2012-10 | 100 | 136 | 2499 | Platform/Chassis |
| ISUZU D-MAX I Platform/Chassis (TFR, TFS) Construction Year to 201205 Fitting Position Front Axle | 2007-01 - 2012-06 | 120 | 163 | 2999 | Platform/Chassis |
| ISUZU D-MAX II Platform/Chassis (TFR, TFS) Construction Year from 201510 Fitting Position Front Axle Vehicle Equipment for vehicles with Single Cab | 2012-06 - | 120 | 163 | 2499 | Platform/Chassis |
24.0127-0104.1
Hoja técnica
- Estado del artículo
- Ordenable
- Marca de automóviles
- Isuzu
- Número de Comercio
- 427104
- País de origen
- Italia
- Altura
- 40,0
- Diámetro exterior [mm]
- 280,0
- Grosor del disco de freno [mm]
- 27,0
- Tipo de disco de freno
- Ventilado
- Superficie
- Revestido
- Número de agujeros para los tornillos
- 6
- Diámetro del agujero del perno [mm]
- 109,0
- Diámetro de centrado [mm]
- 88,0
- Diámetro interior [mm]
- 148,0
- Tamaño del hilo
- M12x1,25
- Espesor mínimo [mm]
- 25,6
Referencias específicas
- ean13
- 4006633470056
- MPN
- 2401270104102
ATE 24.0127-0104.1
(240127-01041)
- Diámetro exterior [mm]: 280,0
- Diámetro interior [mm]: 148,0
- Grosor del disco de freno [mm]: 27,0
- Número de agujeros de perno: 6
- 2 piezas de disco de freno
- Número de intercambio: 427104
