ATE Originale 2-teilige Bremsscheibe (24010901311) für Mazda
65,34 €
(inkl. MwSt.)
54,00 € Steuerexzl.
Teilenummer:
ATE 24.0109-0131.1
(240109-01311)
- Außendurchmesser [mm]: 251,0
- Innendurchmesser [mm]: 125,0
- Bremsscheibendicke [mm]: 9,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile Bremsscheiben
- Handelsnummer: 409131
Logistische Informationen:
- Ean-Code: 4006633025669
- Gewicht: 6.21kg
Specification of ATE 24.0109-0131.1 / 240109-01311 / 24010901311:
| OE Number | Reference info |
| MAZDA BR74-26-251A | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BB4C-26-251 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BR74-26-251E | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BB4C-26-251B | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BB4C-26-251C | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA B530-26-251A | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BB4C-26-251A | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA BR74-26-251B | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| MAZDA 323 C IV (BG) Fitting Position Rear Axle | 1989-09 - 1993-03 | 94 | 128 | 1840 | Hatchback |
| MAZDA 323 C IV (BG) Fitting Position Rear Axle | 1989-09 - 1993-03 | 103 | 140 | 1840 | Hatchback |
| MAZDA 323 C IV (BG) Fitting Position Rear Axle | 1990-09 - 1992-12 | 120 | 163 | 1840 | Hatchback |
| MAZDA 323 F IV (BG) Construction Year from 198909 Fitting Position Rear Axle | 1989-08 - 1994-07 | 76 | 103 | 1840 | Hatchback |
| MAZDA 323 F IV (BG) Construction Year from 198909 Fitting Position Rear Axle | 1989-08 - 1994-07 | 94 | 128 | 1840 | Hatchback |
| MAZDA 323 F IV (BG) Fitting Position Rear Axle | 1989-09 - 1993-03 | 103 | 140 | 1840 | Hatchback |
| MAZDA 323 S IV (BG) Construction Year from 198909 Fitting Position Rear Axle | 1989-08 - 1994-07 | 76 | 103 | 1840 | Saloon |
| MAZDA 323 S IV (BG) Construction Year from 198909 Fitting Position Rear Axle | 1989-06 - 1994-07 | 94 | 128 | 1840 | Saloon |
| MAZDA 323 S IV (BG) Fitting Position Rear Axle | 1991-01 - 1994-07 | 120 | 163 | 1840 | Saloon |
| MAZDA MX-3 (EC) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1991-05 - 1993-10 | 66 | 90 | 1597 | Coupe |
| MAZDA MX-3 (EC) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1993-11 - 1998-09 | 79 | 107 | 1597 | Coupe |
| MAZDA MX-3 (EC) Fitting Position Rear Axle | 1994-01 - 1997-10 | 95 | 129 | 1845 | Coupe |
| MAZDA MX-3 (EC) Fitting Position Rear Axle | 1992-01 - 1994-01 | 98 | 133 | 1845 | Coupe |
| MAZDA MX-5 I (NA) Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1995-01 - 1998-04 | 66 | 90 | 1598 | Convertible |
| MAZDA MX-5 I (NA) Construction Year to 199308 Braking/Driving Dynamics for vehicles with ABS Fitting Position Rear Axle | 1990-05 - 1994-01 | 85 | 115 | 1597 | Convertible |
| MAZDA MX-5 I (NA) Fitting Position Rear Axle | 1993-01 - 1998-04 | 96 | 130 | 1840 | Convertible |
| MAZDA MX-5 II (NB) Construction Year to 200307 Fitting Position Rear Axle | 1998-05 - 2005-10 | 81 | 110 | 1597 | Convertible |
| MAZDA MX-5 II (NB) Construction Year from 199805 Fitting Position Rear Axle | 1998-01 - 2002-07 | 103 | 140 | 1839 | Convertible |
| MAZDA MX-5 II (NB) Construction Year to 200307 Fitting Position Rear Axle | 1998-05 - 2005-10 | 103 | 140 | 1840 | Convertible |
24.0109-0131.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Mazda
- Handelsnummer
- 409131
- Herkunftsland
- China
- Höhe
- 34,5
- Außendurchmesser [mm]
- 251,0
- Bremsscheibendicke [mm]
- 9,0
- Bremsscheibentyp
- Solide
- Oberfläche
- Coated
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 100,0
- Zentrierungsdurchmesser [mm]
- 55,0
- Innendurchmesser [mm]
- 125,0
- Bohrdurchmesser [mm]
- 13,0
- Mindestdicke [mm]
- 8,0
Spezifische Referenzen
- ean13
- 4006633025669
- Hersteller-Teilenummer (MPN)
- 2401090131102
ATE 24.0109-0131.1
(240109-01311)
- Außendurchmesser [mm]: 251,0
- Innendurchmesser [mm]: 125,0
- Bremsscheibendicke [mm]: 9,0
- Anzahl der Bolzenlöcher: 4
- 2 Teile Bremsscheiben
- Handelsnummer: 409131
