ATE Originale zweiteilige Bremsscheibe (24011201991) für Fiat
101,64 €
(inkl. MwSt.)
84,00 € Steuerexzl.
Teilenummer:
ATE 24.0112-0199.1
(240112-01991)
- Außendurchmesser [mm]: 305,0
- Innendurchmesser [mm]: 167,5
- Bremsscheibendicke [mm]: 12,0
- Anzahl der Bolzenlöcher: 5
- 2 Teile Bremsscheiben
- Handelsnummer: 412199
Logistische Informationen:
- Ean-Code: 4006633390293
- Gewicht: 11.32kg
Specification of ATE 24.0112-0199.1 / 240112-01991 / 24011201991:
| OE Number | Reference info |
| FIAT K04721996AA | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| FIAT K04721996AB | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 125 | 170 | 2360 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2016-12 | 206 | 280 | 3604 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 206 | 280 | 3604 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 100 | 136 | 1956 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 103 | 140 | 1956 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 120 | 163 | 1956 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 120 | 163 | 1956 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 125 | 170 | 1956 | MPV |
| FIAT FREEMONT (345_) Fitting Position Rear Axle Equipment Code BRF | 2011-08 - 2015-12 | 125 | 170 | 1956 | MPV |
24.0112-0199.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Fiat
- Handelsnummer
- 412199
- Herkunftsland
- Tschechien
- Höhe
- 33,0
- Außendurchmesser [mm]
- 305,0
- Bremsscheibendicke [mm]
- 12,0
- Bremsscheibentyp
- Solide
- Verarbeitung
- Kohlenstoffhoch
- Oberfläche
- Coated
- Anzahl der Schraublöcher
- 5
- Bolzenlochdurchmesser [mm]
- 127,0
- Zentrierungsdurchmesser [mm]
- 72,5
- Innendurchmesser [mm]
- 167,5
- Bohrdurchmesser [mm]
- 14,0
- Mindestdicke [mm]
- 10,4
Spezifische Referenzen
- ean13
- 4006633390293
- Hersteller-Teilenummer (MPN)
- 2401120199102
ATE 24.0112-0199.1
(240112-01991)
- Außendurchmesser [mm]: 305,0
- Innendurchmesser [mm]: 167,5
- Bremsscheibendicke [mm]: 12,0
- Anzahl der Bolzenlöcher: 5
- 2 Teile Bremsscheiben
- Handelsnummer: 412199
