ATE Originale zweiteilige Bremsscheibe (24012202201) für Audi
141,57 €
(inkl. MwSt.)
117,00 € Steuerexzl.
Teilenummer:
ATE 24.0122-0220.1
(240122-02201)
- Außendurchmesser [mm]: 300,0
- Innendurchmesser [mm]: 194,0
- Bremsscheibendicke [mm]: 22,0
- Anzahl der Bolzenlöcher: 5
- 2 Teile Bremsscheiben
- Handelsnummer: 422220
Logistische Informationen:
- Ean-Code: 4006633221481
- Gewicht: 13.13kg
Specification of ATE 24.0122-0220.1 / 240122-02201 / 24012202201:
| OE Number | Reference info |
| VAG 8E0 615 601 K | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 8E0615601K | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 8E0 615 601 R | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 8E0615601R | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| AUDI A4 B6 (8E2) Fitting Position Rear Axle | 2003-03 - 2004-12 | 253 | 344 | 4163 | Saloon |
| AUDI A4 B6 Avant (8E5) Fitting Position Rear Axle | 2003-03 - 2004-12 | 253 | 344 | 4163 | Estate |
| AUDI A4 B6 Convertible (8H7) Fitting Position Rear Axle | 2004-03 - 2005-12 | 253 | 344 | 4163 | Convertible |
| AUDI A4 B7 Convertible (8HE) Fitting Position Rear Axle | 2005-11 - 2009-03 | 253 | 344 | 4163 | Convertible |
| AUDI A4 B7 (8EC) Fitting Position Rear Axle | 2004-11 - 2008-06 | 253 | 344 | 4163 | Saloon |
| AUDI A4 B7 Avant (8ED) Fitting Position Rear Axle | 2004-11 - 2008-06 | 253 | 344 | 4163 | Estate |
24.0122-0220.1
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Audi
- Handelsnummer
- 422220
- Herkunftsland
- Deutschland
- Höhe
- 36,2
- Außendurchmesser [mm]
- 300,0
- Bremsscheibendicke [mm]
- 22,0
- Bremsscheibentyp
- Entlüftet
- Verarbeitung
- Kohlenstoffhoch
- Oberfläche
- Coated
- Anzahl der Schraublöcher
- 5
- Bolzenlochdurchmesser [mm]
- 112,0
- Zentrierungsdurchmesser [mm]
- 68,0
- Innendurchmesser [mm]
- 194,0
- Bohrdurchmesser [mm]
- 15,3
- Mindestdicke [mm]
- 20,0
Spezifische Referenzen
- ean13
- 4006633221481
- Hersteller-Teilenummer (MPN)
- 2401220220102
ATE 24.0122-0220.1
(240122-02201)
- Außendurchmesser [mm]: 300,0
- Innendurchmesser [mm]: 194,0
- Bremsscheibendicke [mm]: 22,0
- Anzahl der Bolzenlöcher: 5
- 2 Teile Bremsscheiben
- Handelsnummer: 422220
