2 pieces of ATE original Brake Disk (24011601091) for Volkswagen (VW)
€112.53
(tax incl.)
€93.00 tax excl.
Part-number:
ATE 24.0116-0109.1
(240116-01091)
- Outer Diameter [mm]: 258,0
- Inner Diameter [mm]: 135,0
- Brake Disc Thickness [mm]: 16,0
- Number of Bolt Holes: 5
- 2 pieces of Brake Disc
- Trade Number: 416109
Logistical information:
- Ean Code: 4006633138888
- Weight: 11.14kg
Specification of ATE 24.0116-0109.1 / 240116-01091 / 24011601091:
| OE Number | Reference info |
| VAG 251 407 615 Q | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 251407615Q | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 251 407 615 B | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 251407615B | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| VW TRANSPORTER T3 Van (24_, 25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1984-11 - 1992-07 | 57 | 78 | 1913 | Van |
| VW TRANSPORTER T3 Van (24_, 25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1985-08 - 1992-07 | 70 | 95 | 2109 | Van |
| VW TRANSPORTER T3 Van (24_, 25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-03 - 1992-07 | 82 | 112 | 2109 | Van |
| VW TRANSPORTER T3 Van (24_, 25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-03 - 1992-07 | 51 | 69 | 1588 | Van |
| VW TRANSPORTER T3 Bus (25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1985-02 - 1992-07 | 57 | 78 | 1913 | Bus |
| VW TRANSPORTER T3 Bus (25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1985-08 - 1992-07 | 70 | 95 | 2109 | Bus |
| VW TRANSPORTER T3 Bus (25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-01 - 1992-07 | 82 | 112 | 2109 | Bus |
| VW TRANSPORTER T3 Bus (25_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-03 - 1992-07 | 51 | 70 | 1588 | Bus |
| VW TRANSPORTER T3 Platform/Chassis (24_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1984-12 - 1992-07 | 57 | 78 | 1913 | Platform/Chassis |
| VW TRANSPORTER T3 Platform/Chassis (24_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1985-08 - 1992-07 | 70 | 95 | 2109 | Platform/Chassis |
| VW TRANSPORTER T3 Platform/Chassis (24_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-03 - 1992-07 | 82 | 112 | 2109 | Platform/Chassis |
| VW TRANSPORTER T3 Platform/Chassis (24_) Fitting Position Front Axle Rim Size [inch] 14.0 Inch | 1986-03 - 1992-07 | 51 | 69 | 1588 | Platform/Chassis |
24.0116-0109.1
Data sheet
- Article Status
- Orderable
- Car Brand
- Volkswagen (VW)
- Trade Number
- 416109
- Country Of Origin
- Czechia
- Height
- 57,5
- Outer Diameter [mm]
- 258,0
- Brake Disc Thickness [mm]
- 16,0
- Brake Disc Type
- solid
- Number of Bolt Holes
- 5
- Bolt Hole Diameter [mm]
- 112,0
- Centering Diameter [mm]
- 67,0
- Inner Diameter [mm]
- 135,0
- Bore Diameter [mm]
- 15,5
- Minimum Thickness [mm]
- 13,0
Specific References
- EAN13
- 4006633138888
- MPN
- 2401160109101
ATE 24.0116-0109.1
(240116-01091)
- Outer Diameter [mm]: 258,0
- Inner Diameter [mm]: 135,0
- Brake Disc Thickness [mm]: 16,0
- Number of Bolt Holes: 5
- 2 pieces of Brake Disc
- Trade Number: 416109
