ATE Originale zweiteilige Bremstrommel (24022030082) für Ford
105,27 €
(inkl. MwSt.)
87,00 € Steuerexzl.
Teilenummer:
ATE 24.0220-3008.2
(240220-30082)
- Außendurchmesser [mm]: 240,0
- Innendurchmesser [mm]: 203,0
- Trägerplattendurchmesser [mm]: 63,5
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480075
- Ean-Code: 4006633066822
- Gewicht: 7.54kg
Specification of ATE 24.0220-3008.2 / 240220-30082 / 24022030082:
| OE Number | Reference info |
| FORD 7098234 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| FORD 6192490 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| FORD COURIER Pickup Fitting Position Rear Axle | 2001-08 - 2011-12 | 74 | 101 | 1596 | Pickup |
| FORD FIESTA Hatchback Van (FVD) Construction Year from 199109 Fitting Position Rear Axle | 1989-03 - 1995-12 | 44 | 60 | 1753 | Hatchback Van |
| FORD COURIER Box Body/MPV (F3L, F5L) Fitting Position Rear Axle | 1991-09 - 1996-02 | 44 | 60 | 1299 | Box Body/MPV |
| FORD COURIER Box Body/MPV (F3L, F5L) Fitting Position Rear Axle | 1991-09 - 1996-02 | 44 | 60 | 1753 | Box Body/MPV |
| FORD COURIER Box Body/MPV (J5_, J3_) Construction Year to 200203 Fitting Position Rear Axle | 1996-02 - 2003-08 | 44 | 60 | 1299 | Box Body/MPV |
| FORD COURIER Box Body/MPV (J5_, J3_) Construction Year to 200203 Fitting Position Rear Axle | 1996-02 - 2002-04 | 44 | 60 | 1753 | Box Body/MPV |
| FORD FIESTA Hatchback Van (JV_) Construction Year to 200203 Fitting Position Rear Axle | 1998-05 - 2002-04 | 44 | 60 | 1753 | Hatchback Van |
| FORD FIESTA Hatchback Van (JV_) Construction Year to 200203 Fitting Position Rear Axle | 2000-03 - 2003-08 | 55 | 75 | 1753 | Hatchback Van |
24.0220-3008.2
Datenblatt
- Artikelstatus
- Bestellbar
- Automarke
- Ford
- Handelsnummer
- 480075
- Herkunftsland
- Italien
- Höhe
- 59,0
- Außendurchmesser [mm]
- 240,0
- Anzahl der Schraublöcher
- 4
- Bolzenlochdurchmesser [mm]
- 108,0
- Trägerplattendurchmesser [mm]
- 63,5
- Innendurchmesser [mm]
- 203,0
- Bohrdurchmesser [mm]
- 13,5
- Max. Bohrende Dimension [mm]
- 204,0
- Innenhöhe der Bremstrommel [mm]
- 45,0
Spezifische Referenzen
- ean13
- 4006633066822
- Hersteller-Teilenummer (MPN)
- 2402203008202
ATE 24.0220-3008.2
(240220-30082)
- Außendurchmesser [mm]: 240,0
- Innendurchmesser [mm]: 203,0
- Trägerplattendurchmesser [mm]: 63,5
- Anzahl der Bolzenlöcher: 4
- 2 Teile der Bremstrommel
- Handelsnummer: 480075
