ATE Original-2-teilige Bremsscheibe (24011601411) für Piaggio
search
  • ATE Original-2-teilige Bremsscheibe (24011601411) für Piaggio
  • ATE Original-2-teilige Bremsscheibe (24011601411) für Piaggio

ATE Original-2-teilige Bremsscheibe (24011601411) für Piaggio

68,97 € (inkl. MwSt.)

57,00 € Steuerexzl.

Teilenummer:

ATE 24.0116-0141.1
(240116-01411)

  • Außendurchmesser [mm]: 330,0
  • Innendurchmesser [mm]: 172,0
  • Bremsscheibendicke [mm]: 24,0
  • Anzahl der Bolzenlöcher: 5
  • 2 Teile Bremsscheiben
  • Handelsnummer: 416141
Logistische Informationen:
75,0Klicken Sie hier für detaillierte Informationen.
  • Ean-Code: 4006633470858
  • Gewicht: 7.16kg
Menge

Specification of ATE 24.0116-0141.1 / 240116-01411 / 24011601411:

OE NumberReference info
PIAGGIO 4351287523Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287523000Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287Z02Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287Z02000Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)

ModelModel YearkWHPCCType
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 -1115CCVan
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -1824CCVan
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-05 -48651295Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 - 2010-1248651296Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 - 2010-1248651296Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -53721308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -53721308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-07 -54731299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-01 -61831299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-01 -61831299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1995-05 -26351221Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -47641201Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-04 -28381371Van
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-06 -1115CCPlatform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -1824CCPlatform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1994-07 -3548993Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-06 - 2010-1248651296Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -53721308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -53721308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-07 -54731299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2015-11 -59801299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-01 -59801299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2015-11 -61831299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-01 -61831299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1995-05 -26351221Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -47641201Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-04 -28381371Platform/Chassis
PIAGGIO PORTER Bus

Fitting Position Front Axle		1995-01 -1115CCBus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -1824CCBus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2015-11 -61831299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2015-11 -61831299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2016-07 -54731299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -52711308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -52711308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -53721308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -53721308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -47641201Bus
24.0116-0141.1

Datenblatt

Artikelstatus
Bestellbar
Automarke
Piaggio
Handelsnummer
416141
Herkunftsland
China
Zusätzliche Informationen
mit Schrauben/Schrauben
Höhe
66,0
Außendurchmesser [mm]
330,0
Bremsscheibendicke [mm]
24,0
Bremsscheibentyp
Entlüftet
Zweiteilige Bremsscheibe
Verarbeitung
Kohlenstoffhoch
Oberfläche
Coated
Anzahl der Schraublöcher
5
Bolzenlochdurchmesser [mm]
120,0
Zentrierungsdurchmesser [mm]
75,0
Innendurchmesser [mm]
172,0
Bohrdurchmesser [mm]
16,5
Mindestdicke [mm]
22,4

Spezifische Referenzen

ean13
4006633470858
Hersteller-Teilenummer (MPN)
2401160141102
