ATE Originele 2-delige remschijf (24011601411) voor Piaggio
search
  • ATE Originele 2-delige remschijf (24011601411) voor Piaggio
  • ATE Originele 2-delige remschijf (24011601411) voor Piaggio

ATE Originele 2-delige remschijf (24011601411) voor Piaggio

€ 68,97 (incl. btw)

€ 57,00 belastingexcl.

Onderdeelnummer:

ATE 24.0116-0141.1
(240116-01411)

  • Buitendiameter [mm]: 330,0
  • Binnendiameter [mm]: 172,0
  • Remschijfdikte [mm]: 24,0
  • Aantal bolt holes: 5
  • 2 stukken remschijf
  • Handelsnummer: 416141
Logistieke informatie:
75,0Klik hier voor gedetailleerde informatie.
  • Ean Code: 4006633470858
  • Gewicht: 7.16kg
Aantal

Specification of ATE 24.0116-0141.1 / 240116-01411 / 24011601411:

OE NumberReference info
PIAGGIO 4351287523Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287523000Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287Z02Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)
PIAGGIO 4351287Z02000Please observe the vehicle manufacturer's specifications.
Always compare the old and new part (especially the OE number)

ModelModel YearkWHPCCType
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 -1115CCVan
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -1824CCVan
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-05 -48651295Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 - 2010-1248651296Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-06 - 2010-1248651296Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -52711308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -53721308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -53721308Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-07 -54731299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-01 -61831299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2016-01 -61831299Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1995-05 -26351221Van
PIAGGIO PORTER Van

Fitting Position Front Axle		2011-01 -47641201Van
PIAGGIO PORTER Van

Fitting Position Front Axle		1998-04 -28381371Van
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-06 -1115CCPlatform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -1824CCPlatform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1994-07 -3548993Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-06 - 2010-1248651296Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -52711308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -53721308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -53721308Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-07 -54731299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2015-11 -59801299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-01 -59801299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2015-11 -61831299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2016-01 -61831299Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1995-05 -26351221Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		2011-01 -47641201Platform/Chassis
PIAGGIO PORTER Platform/Chassis

Fitting Position Front Axle		1998-04 -28381371Platform/Chassis
PIAGGIO PORTER Bus

Fitting Position Front Axle		1995-01 -1115CCBus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -1824CCBus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2015-11 -61831299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2015-11 -61831299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2016-07 -54731299Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -52711308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -52711308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -53721308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -53721308Bus
PIAGGIO PORTER Bus

Fitting Position Front Axle		2011-01 -47641201Bus
24.0116-0141.1

Datasheet

Artikelstatus
Bestelbaar
Automerk
Piaggio
Handelsnummer
416141
Land van Herkomst
China
Aanvullende informatie
met bouten/schroeven
Hoogte
66,0
Buitendiameter [mm]
330,0
Remschijfdikte [mm]
24,0
Type remschijf
Geventileerd
Tweedelige remschijf
Verwerking
Hoogkoolstof
Oppervlakte
Gecoate
Aantal boltgaten
5
Diameter van het schroefgat [mm]
120,0
Centreringsdiameter [mm]
75,0
Binnendiameter [mm]
172,0
Bordiameter [mm]
16,5
Minimale dikte [mm]
22,4

Specifieke referenties

ean13
4006633470858
MPN
2401160141102
