ATE Disque de frein original en 2 pièces (24011601411) pour Piaggio
68,97 €
TTC
57,00 € fiscalité ex.
Numéro de pièce :
ATE 24.0116-0141.1
(240116-01411)
- Diamètre extérieur [mm] : 330,0
- Diamètre intérieur [mm] : 172,0
- Épaisseur du disque de frein [mm] : 24,0
- Nombre de trous de boulon : 5
- 2 pièces de disque de frein
- Numéro de l’échange : 416141
Informations logistiques :
- Code Ean : 4006633470858
- Poids : 7.16kg
Specification of ATE 24.0116-0141.1 / 240116-01411 / 24011601411:
| OE Number | Reference info |
| PIAGGIO 4351287523 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287523000 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287Z02 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287Z02000 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - | 11 | 15 | CC | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-05 - | 48 | 65 | 1295 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1995-05 - | 26 | 35 | 1221 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-04 - | 28 | 38 | 1371 | Van |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-06 - | 11 | 15 | CC | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1994-07 - | 35 | 48 | 993 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2015-11 - | 59 | 80 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-01 - | 59 | 80 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1995-05 - | 26 | 35 | 1221 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-04 - | 28 | 38 | 1371 | Platform/Chassis |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 1995-01 - | 11 | 15 | CC | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Bus |
24.0116-0141.1
Fiche technique
- Statut de l’article
- Ordonnance
- Marque automobile
- Piaggio
- Numéro de trade
- 416141
- Pays d’origine
- Chine
- Informations supplémentaires
- avec des boulons/vis
- Hauteur
- 66,0
- Diamètre extérieur [mm]
- 330,0
- Épaisseur du disque de frein [mm]
- 24,0
- Type à disque de frein
- Disque de frein en deux parties
Ventilé - Traitement
- Haute émission de carbone
- Surface
- Enduit
- Nombre de trous de boulons
- 5
- Diamètre du trou de boulon [mm]
- 120,0
- Diamètre de centrage [mm]
- 75,0
- Diamètre intérieur [mm]
- 172,0
- Diamètre du canon [mm]
- 16,5
- Épaisseur minimale [mm]
- 22,4
Références spécifiques
- EAN-13
- 4006633470858
- MPN
- 2401160141102
ATE 24.0116-0141.1
(240116-01411)
- Diamètre extérieur [mm] : 330,0
- Diamètre intérieur [mm] : 172,0
- Épaisseur du disque de frein [mm] : 24,0
- Nombre de trous de boulon : 5
- 2 pièces de disque de frein
- Numéro de l’échange : 416141
