ATE Disco de freno original de 2 piezas (24011601411) para Piaggio
68,97 €
(impuestos inc.)
57,00 € fiscales excl.
Número de parte:
ATE 24.0116-0141.1
(240116-01411)
- Diámetro exterior [mm]: 330,0
- Diámetro interior [mm]: 172,0
- Grosor del disco de freno [mm]: 24,0
- Número de agujeros de perno: 5
- 2 piezas de disco de freno
- Número de intercambio: 416141
Información logística:
- Código Ean: 4006633470858
- Peso: 7.16kg
Specification of ATE 24.0116-0141.1 / 240116-01411 / 24011601411:
| OE Number | Reference info |
| PIAGGIO 4351287523 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287523000 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287Z02 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| PIAGGIO 4351287Z02000 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - | 11 | 15 | CC | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-05 - | 48 | 65 | 1295 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1995-05 - | 26 | 35 | 1221 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Van |
| PIAGGIO PORTER Van Fitting Position Front Axle | 1998-04 - | 28 | 38 | 1371 | Van |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-06 - | 11 | 15 | CC | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1994-07 - | 35 | 48 | 993 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-06 - 2010-12 | 48 | 65 | 1296 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2015-11 - | 59 | 80 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-01 - | 59 | 80 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2016-01 - | 61 | 83 | 1299 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1995-05 - | 26 | 35 | 1221 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Platform/Chassis |
| PIAGGIO PORTER Platform/Chassis Fitting Position Front Axle | 1998-04 - | 28 | 38 | 1371 | Platform/Chassis |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 1995-01 - | 11 | 15 | CC | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 18 | 24 | CC | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2015-11 - | 61 | 83 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2016-07 - | 54 | 73 | 1299 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 52 | 71 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 53 | 72 | 1308 | Bus |
| PIAGGIO PORTER Bus Fitting Position Front Axle | 2011-01 - | 47 | 64 | 1201 | Bus |
24.0116-0141.1
Hoja técnica
- Estado del artículo
- Ordenable
- Marca de automóviles
- Piaggio
- Número de Comercio
- 416141
- País de origen
- China
- Información adicional
- con tornillos/tornillos
- Altura
- 66,0
- Diámetro exterior [mm]
- 330,0
- Grosor del disco de freno [mm]
- 24,0
- Tipo de disco de freno
- Disco de freno de dos piezas
Ventilado - Procesamiento
- Alto en carbono
- Superficie
- Revestido
- Número de agujeros para los tornillos
- 5
- Diámetro del agujero del perno [mm]
- 120,0
- Diámetro de centrado [mm]
- 75,0
- Diámetro interior [mm]
- 172,0
- Diámetro del diámetro del diámetro [mm]
- 16,5
- Espesor mínimo [mm]
- 22,4
Referencias específicas
- ean13
- 4006633470858
- MPN
- 2401160141102
ATE 24.0116-0141.1
(240116-01411)
- Diámetro exterior [mm]: 330,0
- Diámetro interior [mm]: 172,0
- Grosor del disco de freno [mm]: 24,0
- Número de agujeros de perno: 5
- 2 piezas de disco de freno
- Número de intercambio: 416141
