ATE Originele 2-stuks remtrommel (24021800521) voor Daihatsu, Subaru
€ 94,38
(incl. btw)
€ 78,00 belastingexcl.
Onderdeelnummer:
ATE 24.0218-0052.1
(240218-00521)
- Buitendiameter [mm]: 220,0
- Binnendiameter [mm]: 180,0
- Draagplaatdiameter [mm]: 55,0
- Aantal boutgaten: 4
- 2 Stukken Remtrommel
- Handelsnummer: 480351
- Ean Code: 4006633509756
- Gewicht: 6.42kg
Specification of ATE 24.0218-0052.1 / 240218-00521 / 24021800521:
| OE Number | Reference info |
| DAIHATSU 42431-B1020-000 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| DAIHATSU 42431-B1020 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| SUBARU 42431B1020 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| TOYOTA 42431B1020 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| DAIHATSU CUORE VII (L275_, L285_, L276_) Construction Year from 200709 Construction Year to 201301 Braking/Driving Dynamics for vehicles with ESP Fitting Position Rear Axle |
2007-04 - | 51 | 70 | 998 | Hatchback |
| DAIHATSU MATERIA (M4_) Construction Year to 201207 Fitting Position Rear Axle |
2006-10 - | 67 | 91 | 1298 | MPV |
| DAIHATSU MATERIA (M4_) Construction Year to 201207 Fitting Position Rear Axle |
2006-10 - | 76 | 103 | 1495 | MPV |
| DAIHATSU MATERIA (M4_) Construction Year to 201207 Fitting Position Rear Axle |
2006-10 - | 76 | 103 | 1495 | MPV |
| DAIHATSU SIRION (M3_) Construction Year to 201301 Fitting Position Rear Axle |
2005-01 - 2013-06 | 51 | 70 | 998 | Hatchback |
| DAIHATSU SIRION (M3_) Construction Year to 201301 Fitting Position Rear Axle |
2005-01 - | 64 | 87 | 1298 | Hatchback |
| DAIHATSU SIRION (M3_) Construction Year to 201301 Fitting Position Rear Axle |
2008-03 - | 67 | 91 | 1298 | Hatchback |
| DAIHATSU SIRION (M3_) Construction Year to 201301 Fitting Position Rear Axle |
2008-03 - | 76 | 103 | 1495 | Hatchback |
| SUBARU JUSTY IV Construction Year from 200709 Construction Year to 201105 Fitting Position Rear Axle |
2007-01 - | 51 | 69 | 998 | Hatchback |
| SUBARU JUSTY IV Construction Year to 201105 Fitting Position Rear Axle |
2007-09 - 2012-03 | 51 | 69 | 998 | Hatchback |
| SUBARU JUSTY IV Construction Year to 201105 Fitting Position Rear Axle Country Specific Design Switzerland |
2008-03 - | 67 | 91 | 1298 | Hatchback |
24.0218-0052.1
Datasheet
- Artikelstatus
- Bestelbaar
- Automerk
- Daihatsu
Subaru - Handelsnummer
- 480351
- Land van Herkomst
- China
- Hoogte
- 46,8
- Buitendiameter [mm]
- 220,0
- Oppervlakte
- geschilderd
- Aantal boltgaten
- 4
- Diameter van het schroefgat [mm]
- 100,0
- Diameter van de ondersteuningsplaat [mm]
- 55,0
- Binnendiameter [mm]
- 180,0
- Bordiameter [mm]
- 14,8
- Max. Afborende Dimensie [mm]
- 181,0
- Binnenhoogte van de remtrommel [mm]
- 33,6
Specifieke referenties
- ean13
- 4006633509756
- MPN
- 2402180052102
ATE 24.0218-0052.1
(240218-00521)
- Buitendiameter [mm]: 220,0
- Binnendiameter [mm]: 180,0
- Draagplaatdiameter [mm]: 55,0
- Aantal boutgaten: 4
- 2 Stukken Remtrommel
- Handelsnummer: 480351
