ATE Originele 2-delige remschijf (24012203181) voor Mazda
€ 90,75
(incl. btw)
€ 75,00 belastingexcl.
Onderdeelnummer:
ATE 24.0122-0318.1
(240122-03181)
- Buitendiameter [mm]: 258,0
- Binnendiameter [mm]: 125,0
- Remschijfdikte [mm]: 22,0
- Aantal boutgaten: 4
- 2 stukken remschijf
- Handelsnummer: 422318
Logistieke informatie:
- Ean Code: 4006633470032
- Gewicht: 10.58kg
Specification of ATE 24.0122-0318.1 / 240122-03181 / 24012203181:
| OE Number | Reference info |
| MAZDA D09T-33-251 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| MAZDA DA7R-33-251 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| MAZDA 2 Hatchback (DL, DJ) Left-/right-hand drive vehicles for left-hand drive vehicles Fitting Position Front Axle | 2014-08 - | 55 | 75 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Fitting Position Front Axle | 2019-08 - | 55 | 75 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Left-/right-hand drive vehicles for left-hand drive vehicles Fitting Position Front Axle | 2014-08 - | 66 | 90 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Fitting Position Front Axle | 2019-08 - | 66 | 90 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Left-/right-hand drive vehicles for left-hand drive vehicles Fitting Position Front Axle | 2014-08 - | 85 | 115 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Fitting Position Front Axle | 2021-10 - | 85 | 116 | 1496 | Hatchback |
| MAZDA 2 Hatchback (DL, DJ) Fitting Position Front Axle | 2014-08 - | 77 | 105 | 1499 | Hatchback |
| MAZDA MX-5 RF Targa (ND) Fitting Position Front Axle | 2017-08 - 2018-05 | 96 | 131 | 1496 | Targa |
| MAZDA MX-5 RF Targa (ND) Fitting Position Front Axle | 2018-05 - | 97 | 132 | 1496 | Targa |
| MAZDA MX-5 IV (ND__) Fitting Position Front Axle | 2015-06 - | 96 | 131 | 1496 | Convertible |
| MAZDA MX-5 IV (ND__) Fitting Position Front Axle | 2018-05 - | 97 | 132 | 1496 | Convertible |
24.0122-0318.1
Datasheet
- Artikelstatus
- Bestelbaar
- Automerk
- Mazda
- Handelsnummer
- 422318
- Land van Herkomst
- Tsjechië
- Hoogte
- 44,0
- Buitendiameter [mm]
- 258,0
- Remschijfdikte [mm]
- 22,0
- Type remschijf
- Geventileerd
- Oppervlakte
- Gecoate
- Aantal boltgaten
- 4
- Diameter van het schroefgat [mm]
- 100,0
- Centreringsdiameter [mm]
- 55,0
- Binnendiameter [mm]
- 125,0
- Bordiameter [mm]
- 13,2
- Minimale dikte [mm]
- 20,0
Specifieke referenties
- ean13
- 4006633470032
- MPN
- 2401220318102
ATE 24.0122-0318.1
(240122-03181)
- Buitendiameter [mm]: 258,0
- Binnendiameter [mm]: 125,0
- Remschijfdikte [mm]: 22,0
- Aantal boutgaten: 4
- 2 stukken remschijf
- Handelsnummer: 422318
