ATE Disco de freno original de 2 piezas (24011301951) para Chevrolet, Daewoo
68,97 €
(impuestos inc.)
57,00 € fiscales excl.
Número de parte:
ATE 24.0113-0195.1
(240113-01951)
- Diámetro exterior [mm]: 236,0
- Diámetro interior [mm]: 107,5
- Grosor del disco de freno [mm]: 12,6
- Número de agujeros de perno: 4
- 2 piezas de disco de freno
- Número de intercambio: 413195
Información logística:
- Código Ean: 4006633078559
- Peso: 7.35kg
Specification of ATE 24.0113-0195.1 / 240113-01951 / 24011301951:
| OE Number | Reference info |
| CHEVROLET 96320531 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CHEVROLET 96284392 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| CHEVROLET 96455424 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| DAEWOO 96320531 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| DAEWOO 96284392 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| CHEVROLET MATIZ (M200, M250) Construction Year to 201012 Fitting Position Front Axle | 2005-03 - 2013-12 | 38 | 52 | 796 | Hatchback |
| CHEVROLET MATIZ (M200, M250) Fitting Position Front Axle | 2005-03 - 2007-12 | 38 | 52 | 796 | Hatchback |
| CHEVROLET MATIZ (M200, M250) Fitting Position Front Axle | 2005-03 - 2007-12 | 47 | 64 | 995 | Hatchback |
| CHEVROLET MATIZ (M200, M250) Construction Year to 201012 Fitting Position Front Axle | 2007-01 - | 48 | 65 | 995 | Hatchback |
| CHEVROLET MATIZ (M200, M250) Construction Year to 201012 Fitting Position Front Axle | 2005-03 - | 49 | 67 | 995 | Hatchback |
| CHEVROLET MATIZ (M200, M250) Fitting Position Front Axle | 2005-03 - 2011-03 | 49 | 67 | 995 | Hatchback |
| CHEVROLET SPARK Fitting Position Front Axle | 2005-05 - 2010-02 | 37 | 50 | 796 | Hatchback |
| CHEVROLET SPARK Construction Year to 201002 Fitting Position Front Axle | 2005-05 - | 46 | 63 | 995 | Hatchback |
| CHEVROLET SPARK Construction Year to 201002 Fitting Position Front Axle | 2005-05 - | 49 | 67 | 995 | Hatchback |
| DAEWOO MATIZ (M100, M150) Construction Year to 200502 Fitting Position Front Axle | 1998-09 - | 38 | 52 | 796 | Hatchback |
| DAEWOO MATIZ (M100, M150) Construction Year to 200502 Fitting Position Front Axle | 2003-01 - | 47 | 64 | 995 | Hatchback |
24.0113-0195.1
Hoja técnica
- Estado del artículo
- Ordenable
- Marca de automóviles
- Chevrolet
Daewoo - Número de Comercio
- 413195
- País de origen
- Chequia
- Altura
- 35,4
- Diámetro exterior [mm]
- 236,0
- Grosor del disco de freno [mm]
- 12,6
- Tipo de disco de freno
- sólido
- Superficie
- Revestido
- Número de agujeros para los tornillos
- 4
- Diámetro del agujero del perno [mm]
- 102,0
- Diámetro de centrado [mm]
- 86,0
- Diámetro interior [mm]
- 107,5
- Tamaño del hilo
- M10x1,25
- Espesor mínimo [mm]
- 9,7
Referencias específicas
- ean13
- 4006633078559
- MPN
- 2401130195102
ATE 24.0113-0195.1
(240113-01951)
- Diámetro exterior [mm]: 236,0
- Diámetro interior [mm]: 107,5
- Grosor del disco de freno [mm]: 12,6
- Número de agujeros de perno: 4
- 2 piezas de disco de freno
- Número de intercambio: 413195
