ATE Disco de freno original (24042301301) para Cupra, Volkswagen (VW)
68,97 €
(impuestos inc.)
57,00 € fiscales excl.
Número de parte:
ATE 24.0423-0130.1
(240423-01301)
- Diámetro exterior [mm]: 330,0
- Diámetro interior [mm]: 165,5
- Grosor del disco de freno [mm]: 23,0
- Número de agujeros de perno: 5
- Número de intercambio: ED23130
Información logística:
- Código Ean: 4006633506984
- Peso: 8.96kg
Specification of ATE 24.0423-0130.1 / 240423-01301 / 24042301301:
| OE Number | Reference info |
| VAG 1EA 615 301 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| VAG 1EA615301 | Please observe the vehicle manufacturer's specifications. Always compare the old and new part (especially the OE number) |
| Model | Model Year | kW | HP | CC | Type |
| CUPRA BORN (K11, K1G) Fitting Position Front Axle for PR number 1LA | 2021-08 - | 110 | 150 | CC | Hatchback |
| CUPRA BORN (K11, K1G) Fitting Position Front Axle for PR number 1LA | 2021-08 - | 150 | 204 | CC | Hatchback |
| CUPRA BORN (K11, K1G) Fitting Position Front Axle for PR number 1LA | 2021-08 - 2024-05 | 170 | 231 | CC | Hatchback |
| CUPRA BORN (K11, K1G) Fitting Position Front Axle for PR number 1LA | 2021-08 - | 170 | 231 | CC | Hatchback |
| CUPRA BORN (K11, K1G) Fitting Position Front Axle for PR number 1LA | 2024-06 - | 240 | 326 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2021-11 - 2023-05 | 93 | 126 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2020-11 - | 107 | 145 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2020-03 - 2023-05 | 110 | 150 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2024-06 - | 125 | 170 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2019-11 - | 150 | 204 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2021-11 - | 150 | 204 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2024-06 - | 170 | 231 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2021-11 - | 150 | 204 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2024-06 - | 170 | 231 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2024-06 - | 210 | 286 | CC | Hatchback |
| VW ID.3 (E11, E12, E13) Fitting Position Front Axle for PR number 1LA | 2024-08 - | 240 | 326 | CC | Hatchback |
24.0423-0130.1
Hoja técnica
- Estado del artículo
- Ordenable
- Marca de automóviles
- Cupra
Volkswagen (VW) - Número de Comercio
- ED23130
- País de origen
- China
- Información adicional
- con tornillos/tornillos
- Altura
- 49,6
- Diámetro exterior [mm]
- 330,0
- Grosor del disco de freno [mm]
- 23,0
- Tipo de disco de freno
- Ventilado
- Procesamiento
- Alto en carbono
- Superficie
- Revestido
- Número de agujeros para los tornillos
- 5
- Diámetro del agujero del perno [mm]
- 112,0
- Diámetro de centrado [mm]
- 65,0
- Diámetro interior [mm]
- 165,5
- Diámetro del diámetro del diámetro [mm]
- 15,3
- Espesor mínimo [mm]
- 21,5
Referencias específicas
- ean13
- 4006633506984
- MPN
- 2404230130102
ATE 24.0423-0130.1
(240423-01301)
- Diámetro exterior [mm]: 330,0
- Diámetro interior [mm]: 165,5
- Grosor del disco de freno [mm]: 23,0
- Número de agujeros de perno: 5
- Número de intercambio: ED23130
